Sunday, February 2, 2014

3-Stage, Candy or Tri-Coat Paint

Camaro with 3-Stage Pearl paint in process at Almost Everything Auto Body

What is Three Stage Paint?
Three stage paint jobs have the most depth and sometimes appear to change color as a car drives by. The most common three stage paint is pearl white. Intense "Candy Apple Red" and similar paint jobs are also 3-stage. They achieve effects that regular one- and two-stage paints can't. The trick is a middle stage of paint that is translucent (partially transparent.) The middle layers can have a second color and/or pearl dust, mica and metallic flakes in it that allows light to reflect off of the base coat and the various elements differently than if the same elements were simply mixed together in regular paint. The middle stage changes the color of the base stage. It also adds the sparkle or color shifting effect of the pearl, metal or mica flake. In addition, by varying the thickness of the mid-coat layers, you can create increasing variations in the way the paint reacts with light. So at one angle you see one color and level of sparkle and irridescense then at another angle it may look dramatically more light, dark, irridescent or even a different color entirely.

Cost
Three stage paints require a vehicle to be painted three times, as opposed to one or two times with a normal paint job. So there is more labor and materials involved. Additionally, the additives for the middle stage, like pearl dust, are often expensive materials (pearl dust can really be ground-up pearls and mother of pearl.) And last, 3-stage paint jobs take a tremendous amount of skill. So the people who do them well get paid well. A three-stage paint job is not one to pick on a tight budget.

Maintenance
In everyday use, three stage paints should be treated just like any other paint. If possible, park in a garage to minimize fading from the sun. Wash off contaminants as soon as possible. Common paint killers are bug splatter, bird droppings and chemicals that fall on the car as dust or mist. And finally, protect the paint with a good, quality wax. Good waxes are typically the type that you put on, let dry, then work like the dickens to polish to a high luster. If you have a sore arm after applying wax to one fender, it is probably a decent wax. We suggest finding a good detailer and paying him/her to wax your car once or twice a year.

Three stage paints can be difficult or impossible to duplicate if you ever have an accident and need to repair a portion of the paint job. A slight variation in one of the three different paint processes can result in a dramatically different appearance from the rest of the car. Repairs on a vehicle with a manufacturer standard 3-stage paint require a larger repaint area than other paint jobs. For example, a dent on one door may require blending paint across the entire side of the vehicle. For custom or non-standard finishes, you will probably need to repaint the entire vehicle to avoid strange variations in colors and intensities.

Friday, November 20, 2009

Metallic & Pearl Colors

3-Stage Pearl White Paint has an extra shimmer.

Metallic & pearl colored paints use flakes of aluminum metal, mica (a shiny mineral) or "pearl" (iridescent particles often from ground sea shells) to create sparkle, luminosity and more light and color complexity than is found in solid colored paints.

Metallic and pearl colors are available in single-stage, 2-stage & 3-stage paint process technologies but they are not created equal.

The process and materials used in 2-stage paints result in a more uniform layer of color that causes the flakes to lie more flat, reflect more light and create beautiful finishes. The single-stage process is not capable of achieving the same results and certain colors--especially golds, silvers, champagnes and bronzes--can look dull and grey in single-stage when compared to 2-stage and 3-stage paints. When color is important, choose 2-stage paint to achieve the right hue & brilliance.

For certain colors and special effects in finishes like "candies" and pearls--especially pearl white--it may be necessary to go another step into 3-stage paint to achieve the desired result. The Nissan Altima in the photo has a 3-stage pearl white paint job that gives the white a luminosity and brilliance that single- and two-stage paints cannot come close to.



Thursday, November 19, 2009

Two-Stage Paint

This post is the 2nd in a series on Paint Technologies--What do people mean by single-stage, two-stage & three-stage paint? A previous post discussed single-stage paint. This article describes two-stage paint.


The terms "single-stage, two-stage & three-stage describe different types of auto painting processes. Each "stage" is a step in the process. Think of the stages like the layers of rock in the photo below. Each "stage" is like one of the different color bands in the formation. It is a layer of material:



Two-Stage:  It can also be called 2-stage, bi-stage, base-clear, base coat/clear coat, B/C, etc. In this case the 1st of the two stages is the base coat. It contains the colored paint. The 2nd stage is the clear coat--layers of clear paint that go on top of the color paint to provide protection & gloss. So in relation to the rock formation, 2-stage paint is equivalent to two bands of rock stacked together. Auto manufacturers in the USA phased-out single stage paints and transitioned to two-stage or base coat-clear coat paints in 1987.

Any paint is designed to protect the car against damage from sunlight, acid rain, bird droppings and all of the other environmental hazards that your car gets exposed to every day. Reputable shops like Almost Everything Autobody will apply 2-3 coats of base-coat AND 2-3 coats of clear-coat to your vehicle. 2-stage paints cost a little more initially than single-stage paints but are generally a more economical choice when it is important to keep the vehicle looking good, when you want to maintain resale value or you plan to keep the vehicle for more than 3 years because they are easier to maintain, last & look better longer.

Some advantages of 2-stage paints are:
  • Better UV protection & resistance to fading from sunlight
  • Easier maintenance with ability to remove scratches that don't penetrate down to the color layer
  • Better resistance to chipping
  • More variety, better looking & more vibrant colors & metallic finishes
  • Better gloss & "wet" look
  • Easier to achieve uniform color appearance
  • Possible to address cosmetic issues like dust specks and paint runs
  • Generally look better, longer than single stage paints
The process and materials used in 2-stage paints result in a more uniform layer of color that causes metallic paints to be more brilliant. The single-stage process is not capable of achieving the same results and certain colors--especially golds, silvers, champagnes and bronzes--can look dull and grey in single-stage when compared to 2-stage. When color is important, choose 2-stage paint to achieve the right hue & luminosity.

I began to type "disadvantages" but I don't think that the following is really a disadvantage as much as a difference between single-stage and 2-stage paints that may affect the type of paint you choose. When 2-stage paint reaches the end of its useful life, usually 7-14 years after the car was originally built and painted, instead of fading like single-stage paints, the top, clear layer turns cloudy and if not repaired, can start to peel and expose the more fragile color coat and even the metal underneath. We call this delamination. Many customers find failing clear coat ugly and more objectionable than the relatively uniform fading that is found on older-technology single stage paints. It is important to remember that 2-stage paint provides great protection and looks better longer than single-stage paint but, in our opinion, it does fail less gracefully when its time is done.


It is a good idea to get a car re-painted when this delamination starts to happen for a number of reasons--number one being cost. The longer the car goes without new paint, the more damage that happens to the existing paint, the greater the chance for rust and the more work that is required to fix the problem, not to mention, the car becomes embarrassing, looks worn-out and starts to quickly lose value. You should not allow anyone to put new paint on top of delaminating paint. The old, delaminating paint will continue to peel under the new paint and the new paint will quickly peel off just like the old stuff was doing! Don't waste your money on new paint if you don't plan to get the failed paint reconditioned first.

One note of caution, there are cheap paints out there--any of single-stage, two-stage or three-stage can be painted with poor materials that produce lousy results and don't last long. Almost Everything uses only top quality paints from the supplier used on NASA's Space Shuttle, the Golden Gate Bridge and just about every car make & model since the Model T Ford.

We will be posting additional articles that deal with color matching, gloss, texture and "orange peel," wet sanding or color sanding, solids, metallics & pearls. Feel free to drop by our shop if you are near to us and we will be happy to discuss with you.

Sunday, November 15, 2009

Single-Stage Paint


What do people mean by single-stage, two-stage & three-stage paint? It's pretty simple. They are different types of auto painting processes. Each "stage" is a step in the process. Think of the stages like the layers of rock in the photo below. Each "stage" is like one of the different color bands in the formation. It is a layer of material:

Single-Stage:  It can also be called one-stage or 1-stage. Only one type of paint is used to paint the car. The color is uniform in the paint.  So in relation to the rock formation, single-stage paint is equivalent to a single color band of rock.

Single-stage paint is the type used on cars before 1987. After 1987 all manufacturers switched to 2-stage paint. Consider that virtually any house paint, or almost any other type of paint, is a single-stage paint. The single-stage paints available for automotive purposes can be very good stuff. The technology is mature and well understood. Single-stage polyurethanes are available that survive very well against sunlight, acid rain, bird droppings and all of the other environmental hazards that your car gets exposed to every day. Single-stage does NOT mean only one coat of paint. Any reputable shop will apply 2-3 coats of paint to your vehicle. Note that there are also some extremely cheap paints out there--any of single-stage, two-stage or three-stage can be painted with poor materials that produce lousy results and don't last long. Single-stage paints are generally less expensive than 2- or 3-stage paints and can be a great choice for vehicles that you only plan to keep for 1-3 years.
The Lotus Esprit Turbo with single-stage paint from Almost Everything Autobody
There are some things to consider with single-stage paints. We will be posting additional articles that deal with color matching, gloss, texture and "orange peel," wet sanding or color sanding, solids, metallics, pearls. Feel free to drop by our shop if you are near to us and we will be happy to discuss with you.

One note of caution: color match is more difficult with some golds, silvers and champagne colors in single-stage paints and in general, these colors are not as vibrant as with 2-stage paint. We've seen this issue on vehicles painted with any of the top quality paint manufacturers (DuPont, PPG, Sherwin-Williams). That is a big reason why 2- and 3-stage paints were developed.
